Photo of two black OEM replacement fuel tanks for a 2007 Grady-White 360 Express boat, each with a 185-gallon capacity. The tanks have a textured anti-corrosion coating, top-mounted fittings including sender ports, fill and vent fittings, and lifting tabs on the front and rear
3D render of an OEM replacement fuel tank for a 2007 Grady-White 360 Express boat with a 185-gallon nominal capacity. The tank measures 97 inches in length, 24 inches in width, and 26.25 inches in height. Features include top-mounted fittings for fill, vent, sender, and pickups, along with front and rear lifting tabs. WW anchor logo is visible in the bottom right corner
Front view of two light gray 3D-rendered OEM replacement fuel tanks for the 2007 Grady-White 360 Express, each with a 185-gallon capacity. Tanks include front lifting tabs and top-mounted fittings, with the right tank showing a sloped bottom edge for hull conformity
Side view of two black OEM replacement fuel tanks for a 2007 Grady-White 360 Express boat, each with a 185-gallon capacity. The tanks have a textured anti-corrosion coating and distinctive angled bottom edges for hull fit. Visible are top-mounted fittings and manufacturer labels. Transparent background included
Angled rear view of two black OEM replacement fuel tanks for a 2007 Grady-White 360 Express boat, each with a 185-gallon capacity. Tanks are coated with a textured corrosion-resistant finish and feature sloped bottoms, rear lifting tabs, and top-mounted fittings including sender units and fuel lines. Transparent background
Close-up of the manufacturer's label on a Grady-White 360 Express fuel tank made by Welding World Inc., Miami, FL. The label shows part number WW316250, customer QB 2651, 185-gallon capacity, manufactured on 02/01/2023, made from 0.190-inch thick aluminum 5052-H-32. Serial number 2023090. Certified for gasoline, tested to 9 psi under 33 CFR § 183.510(a), and compliant with ISO 8846 and 10088. ABYC and NMMA certification logos and a safety warning are visible
Photo of two black OEM replacement fuel tanks for a 2007 Grady-White 360 Express boat, each with a 185-gallon capacity. The tanks have a textured anti-corrosion coating, top-mounted fittings including sender ports, fill and vent fittings, and lifting tabs on the front and rear
3D render of an OEM replacement fuel tank for a 2007 Grady-White 360 Express boat with a 185-gallon nominal capacity. The tank measures 97 inches in length, 24 inches in width, and 26.25 inches in height. Features include top-mounted fittings for fill, vent, sender, and pickups, along with front and rear lifting tabs. WW anchor logo is visible in the bottom right corner
2007 Grady-White 360 Express boat, a luxury sportfishing vessel with sleek design and robust features for offshore fishing and cruising
Front view of two light gray 3D-rendered OEM replacement fuel tanks for the 2007 Grady-White 360 Express, each with a 185-gallon capacity. Tanks include front lifting tabs and top-mounted fittings, with the right tank showing a sloped bottom edge for hull conformity
Side view of two black OEM replacement fuel tanks for a 2007 Grady-White 360 Express boat, each with a 185-gallon capacity. The tanks have a textured anti-corrosion coating and distinctive angled bottom edges for hull fit. Visible are top-mounted fittings and manufacturer labels. Transparent background included
Angled rear view of two black OEM replacement fuel tanks for a 2007 Grady-White 360 Express boat, each with a 185-gallon capacity. Tanks are coated with a textured corrosion-resistant finish and feature sloped bottoms, rear lifting tabs, and top-mounted fittings including sender units and fuel lines. Transparent background
Close-up of the manufacturer's label on a Grady-White 360 Express fuel tank made by Welding World Inc., Miami, FL. The label shows part number WW316250, customer QB 2651, 185-gallon capacity, manufactured on 02/01/2023, made from 0.190-inch thick aluminum 5052-H-32. Serial number 2023090. Certified for gasoline, tested to 9 psi under 33 CFR § 183.510(a), and compliant with ISO 8846 and 10088. ABYC and NMMA certification logos and a safety warning are visible

Grady-White 24 'en alta mar 1989 - 118 gal. auxiliar Tanque Eliminar Tanque de Combustible Modificado

$ 2,689.00
/
  • Local pickup available
  • Over-sized & over-weight item.
  • Only Ships LTL Freight.
  • Call us Mon.-Fri. 8:30 a.m. to 4:40 p.m. if in any doubt.
  • NOTA IMPORTANTE: El precio base es para retiro local en nuestra SW Miami Shop. Consulte las opciones de embalaje y envío a los 48 estados contiguos. Todos los tanques se fabrican por encargo y el plazo de fabricación es de 2 semanas laborales. La ventana de recolección del tanque terminado también es de 2 semanas laborales, así que asegúrese de poder recibir su tanque terminado dentro de ese plazo.

  • Comprar con confianza. Poco después de que se acredite su pago, se le enviará por correo electrónico un conjunto completo de dibujos para que verifique todas las dimensiones y las posiciones de los accesorios. Si hay alguna diferencia con su antiguo tanque, podemos hacer cualquier modificación razonable para satisfacer sus necesidades.

  • Este es un tanque de modificación popular que une los tanques de combustible principal y auxiliar en un tanque de 118 galones más largo y de mayor capacidad.

    • Construcción de aluminio serie Alcoa ® 5052 H32 de .190 de espesor.

      • Soldado GTAW (TIG) soldado a mano para superar los estándares ASME / ASW D3.7:2004.

        • Sherwin Williams® TarGard® Epoxi pintado para la mejor protección del medio ambiente marino.

          • Interruptor de láminas KUSA® (ex-WEMA) y transmisor de nivel de combustible de flotador NBR.

            NOTA: ¡Compruebe minuciosamente las dimensiones de su tanque! Una vez que se fabrica y / o envía un tanque, no podemos ser responsables de los desajustes y no se aceptarán reembolsos o devoluciones. ¡Todas las ventas son finales!

            Plazo de ejecución de la fabricación (antes del envío): 2 semanas laborales.

            Envío: Solo flete a los 48 estados contiguos. Contáctenos para conocer las opciones de envío con costo adicional para HI y AK. Se aceptan envíos internacionales de transportistas con sede en EE. UU., pero contáctenos primero para coordinar los detalles.

            Due to this item's size and weight we can only ship it in an economical way via Less Than Truckload (LTL) consolidated land shipping, and only to the contiguous 48 States.

            For shipping inquiries to AK, HI, PR, US-VI, and international shipping, please contact us first at sales@weldingworldinc.com.

            All of the destinations above we can only serve as a Free Carrier (or FCA) modality, that requires the customer to contract and pay for their carrier service of choice. We can still ship the item, but only to a warehouse/receiving office within the 48-contiguous States.

            In plain terms what this means is that if you want to ship your product to any non-contiguous US territory or internationally, you, the customer, has to provide us with the warehouse address of the carrier that serves your locality with an address within the contiguous 48-US States, as we do not ship overseas on our own.
